YOUR POSITION：HOME > Machines > Kitchen Paper Rolls Packing Machine >

TP-B30RE Kitchen Roll Tissue Paper Packing Machinery Bunling Wrapping Machine

Price: Negotiable
Model Number: TP-B30RE
Power: 19KW
Application: bundle packing single packed/unpack core/coreless roll paper
Weight: 3400KG
Output: 22Pack/min
Packaging dimension: Length (L): 300-690 Width (W): 160-440 Height (H): 80-280 MM
Place of Origin: CHINA.
Brand Name: IMAKO
Certification: CE, ISO
Minimum Order Quantity: 1 SET
Trading Method: FOB/CIF/EXW Xiamen Port
Delivery Time: 90 Days
Packaging logistics: In wooded cases with fumigation finish or wrapped with plastic film.

Get Quote

+86-15918973337

★Adopts servos control for tissue arrangement, counting, filling preparation, tissue fill to bag, bag catching, bag conveying. This machine is easy to operate and maintain.

★Adopts central vacuum management mode, can efficiency lower power consumption.

★Adopts intelligent sealing system, alternating current control, up & down independent temperature control, can meet different kinds of packaging materials, ensure nice sealing and stably running.

TP-B30RE main parameter configuration
Specification\Model\ ltem	TP-B30REV、TP-B30REM
Scope of Application	Core、coreless roll paper
Feeding type	ASF auto double lanes feeding system
Design speed	22 packs/min
Stable speed	20packs/min(relate to product size)
Gusset type	Vacuum forming mould
Cut off modo	lnsert & cut
Bag storage structure	Dual bag racks
Bag storage qty	600 bags
Bag material	PE film
Compressed air(MAP)	Pressure O.6MPA Flow 30l/min
Power supply	380V/50HZ
Total motor power(KW)	19
Machine weight (KG)	3400
Bag type	premade bag
Servo control shaft nos	10
Electrical control system	VEICHI,MITSUBISHI
Temp.system	YUDILAN
Pneumatic system	SMC.AlRTAC
Optional device	lnk code printer.thermos transfer printer

TP-B30RE series automatic roll paper bundle packing machine is suitable for automatic bundle packing single packed/unpack core/coreless roll paper.


Equipped with functions of waste bag free stop automatic rejection, air source management, fault alarm and display, servo overload protection.

Products Categories

Related Products

More》

Kitchen Towel Packing Machinery Kitchen Paper Bundling Wrapping Machine Kitchen Tissue Packing Machine

TP-B30RE Kitchen Roll Tissue Paper Packing Machinery Bunling Wrapping MachineMain Parts

1. Film Dragging Roller

The Film Dragging Rollers are an important component of the Kitchen paper rolls packing machine. They are used to pull the film across the surface of the Kitchen pape r rolls and ensure that the film is tightly wrapped around the rolls.

2. Best Electric motors

Factors such as the speed, torque, and power output needed to drive the various components are all taken into consideration when selecting the motor.Ensure that the motor is properly installed and maintained，Regular maintenance and inspection can help to prolong the life of the motor.

3. Conveyor Timing Belts

The Belt is designed with specific dimensions and specifications that are tailored to the requirements of Kitchen paper roll packing machine.The belt is also designed with specific grooves and ribs that help to improve its grip on the rollers and ensure smooth and consistent movement.
